CHESTER PRO 32VS Pillar Drill Variable Speeds and Auto Reverse Tapping

Drilling Capacity 31.75mm. Tapping Capacity 20mm in Steel.

• Spindle Taper No.4 Morse
• Drilling Capacity (Mild Steel) 31.75mm
• Drilling Capacity (Cast Iron) 31.75mm
• Tapping Capacity (Mild Steel) 20mm
• Drilling Capacity (Cast Iron) 24mm
• Distance from Spindle to Column 265mm
• Distance from Spindle Nose to Table 820mm Max
• Distance from Spindle Nose to Base 1085 - 1235mm
• Vertical Travel of Table 730mm
• Spindle Travel 150mm Max
• Table Size 334 x 334mm
• Number of Spindle Speed Ranges 2
• Range of Spindle Speeds 100-620 & 620-3300rpm
• Depth Setting & Auto Reverse for Tapping
• Column Diameter 100mm
• Base Working Surface 310x380mm
• Number and Size of T Slots on Base 2 x 14mm
• Main Motor Power 1.5 kW
• Power Supply 400V 3 Phase.
• With Drill Chuck & Arbor, Taper Sleeve, Drift, Crank,
• Interlocked Spindle Guard, Electronic Speed Display, Coolant System. Operation / Parts List
